HB10

HB10-Series LED High Bay Lights provide efficient illumination for warehouses, factories, and logistics centers.
Offered in 100 and 200W power solutions with up to 200 lm/W efficacy, smart sensing, and a compact, durable design – delivering reliable energy savings for industrial environments.

Key Features

Compact Power Range Options

Available in 100W, 150W, and 200W models with 60/90/120° beam angles, ideal for medium-height industrial and commercial spaces.

Multi-Level Efficacy Choices

Select 150, 170, 190, or 200 lm/W to achieve bright, uniform lighting with excellent energy efficiency across large areas.

Intelligent Sensing Support

0–10V dimming, optional 12V aux power, Zhaga interface, and microwave/infrared sensors for smart automation.

Rugged Compact Construction

IP65/IK08 rated ADC12 aluminum housing with PC lens and premium drivers ensures long life and reliable performance in harsh conditions.

Inquire Now

Technical Specifications

Series	HB10-Round UFO LED High Bay Light
Power	100W, 150W, 200W
Lumen Output	14500-40000 lm
Efficacy	150 lm/W, 170 lm/W, 190 lm/W, 200 lm/W
Input Voltage	AC 120-277V 50/60Hz
Color Temperature	3000K / 4000K / 5000K / 5700K / 6500K
CRI	150-170lm/W, Ra: 80±2; 190-200lm/W, Ra: 70±2
Beam Angle	60° / 90° / 120°
Operating Temperature	-30°C to +40°C, RH: 5%-90% non-condensing
IP Rating	IP65
IK Rating	IK08
Housing Material	ADC12 + PC Lens
Mounting	Standard with hanging loop, optional hook, bracket mount, 3/4" tube tooth adapter
Dimming	0-10V
Certifications	CE / RoHS / CCC / CQC
Warranty	5 Years

Technical Documents

Datasheet

Detailed technical parameters and product overview for reference.

Download

IES File

Photometric data for lighting simulation and design software.

Download

Installation Guide

Step-by-step instructions for safe and correct fixture mounting.

Download
