HB08

HB08-Series LED High Bay Lights deliver high-efficacy illumination for warehouses, factories, and stadiums.
With 50-500W options, up to 200lm/W efficiency, superior heat dissipation, and smart controls, they provide reliable, energy-saving performance in demanding industrial environments.

Key Features

Versatile Power & Beam Options

Available in 50W to 500W across six sizes with multiple beam angles, perfectly matching diverse industrial and commercial ceiling heights and lighting needs.

Exceptional Luminous Efficacy

Choose 150, 170, or 200 lm/W options to maximize energy savings while delivering bright, uniform light for large spaces.

Advanced Heat Dissipation

ADC12 die-cast aluminum housing with air convection structure ensures excellent cooling, extending LED life up to 100,000 hours in tough environments.

Intelligent Control Compatibility

Supports 0-10V dimming, Zhaga interface, microwave/infrared sensors, and Bluetooth APP for flexible automation and energy optimization.

Inquire Now

Technical Specifications

Series	HB08-Round UFO LED High Bay Light
Power	50W, 100W, 150W, 200W, 240W, 300W, 400W, 500W
Lumen Output	7500-100000 lm
Efficacy	150 lm/W, 200 lm/W
Input Voltage	AC 120-277V 50/60Hz
Color Temperature	3000K / 4000K / 5000K / 5700K / 6500K
CRI	150-170lm/W, Ra: 80±2; 200lm/W, Ra: 70±2
Beam Angle	30° /60° / 90° / 120°
Operating Temperature	-30°C to +45°C, RH: 5%-90% non-condensing
IP Rating	IP65
IK Rating	IK08
Housing Material	ADC12 + PC Lens
Mounting	Standard with hanging loop, optional hook, bracket mount, 3/4" tube tooth adapter
Dimming	0-10V
Certifications	CE / RoHS / CCC / CQC
Warranty	5 Years

Technical Documents

Datasheet

Detailed technical parameters and product overview for reference.

Download

IES File

Photometric data for lighting simulation and design software.

Download

Installation Guide

Step-by-step instructions for safe and correct fixture mounting.

Download
