LHB04

The LHB04 Series Linear High Bay Light offers high-efficiency illumination (up to 180lm/W) for industrial workshops, warehouses, airports and other venues.
Featuring an integrated heat sink and rugged housing, it delivers reliable performance across high-ceiling venues.

Key Features

Unified Housing Design

Covers 150–240W models within a standardized dimension, simplifying installation and visual consistency across large industrial facilities.

High Thermal Conductivity

A die-cast integrated heat sink provides efficient heat dissipation, ensuring long-lasting performance and reliable operation.

Robust IP65/IK08 Protection

Equipped with a UV-resistant PC lens offering IP65 water resistance and IK08 impact protection for harsh environments.

Smart Control Compatibility

Supports DIP switches for power/CCT adjustment alongside optional Microwave, PIR, and daylight harvesting sensors.

Inquire Now

Technical Specifications

SeriesLHB04-Linear LED High Bay Light
Power150W, 200W, 240W
Lumen Output22500-27000 lm, 30000-36000 lm, 36000-43000 lm
Efficacy150 lm/W, 180 lm/W
Input VoltageAC 120-277V 50/60Hz
Color Temperature3000K / 4000K / 5000K / 5700K / 6500K
CRI150lm/W, Ra: 80±2; 180lm/W, Ra: 70±2
Beam Angle90°*120° / 40°*120°
Operating Temperature-30°C to +45°C, RH: 5%-90% non-condensing
IP RatingIP65
IK Rating
IK08
Housing MaterialHigh-quality Die-cast Aluminum Housing + Optical PC Lens
MountingRope installation
Dimming1-10V
CertificationsCE / RoHS / CQC
Warranty5 Years

Technical Documents

Datasheet

Detailed technical parameters and product overview for reference.

IES File

Photometric data for lighting simulation and design software.

Installation Guide

Step-by-step instructions for safe and correct fixture mounting.
