HB113

Dual‑spectrum HB113 LED high‑bay for livestock – white light plus optimized red/yellow bands to promote animal health, milk output, and fertility, with IP65 rating and 5‑year durability.

Key Features

Dual-Spectrum Animal Lighting

White light plus red or yellow LEDs with independent dimming per unit, letting farmers optimize spectra for poultry growth or livestock health and productivity.

Anti-Ammonia Glass Shield

Tempered glass cover resists ammonia corrosion common in barns and coops, maintaining clarity and protecting LEDs from harsh, humid agricultural environments.

Proven Livestock Benefits

Red light advances poultry maturity and egg yield; yellow light raises milk output to 37.58 kg and lifts first-mating pregnancy rates significantly.

Rugged IP65 Construction

Die-cast ADC12 housing with IP65 and IK07 ratings withstands dust, water jets, and impacts, backed by a 5-year warranty for worry-free farming.

Inquire Now

Technical Specifications

Series	HB113-Livestock and Poultry LED High Bay
Power	120+20W, 200+40W
Lumen Output	18000 lm, 36000 lm
Efficacy	150 lm/W
Input Voltage	AC 120–277V 50/60Hz
Color Temperature	Full Spectrum 5700K
CRI	Ra: 80
Beam Angle	120°
Operating Temperature	-30°C to +50°C, RH: 5%-90% non-condensing
IP Rating	IP65
IK Rating	IK09
Housing Material	ADC12 + Tempered Glass (PC Lens Optional)
Mounting	Bracket Mounting
Dimming	1-10V
Certifications	CE / RoHS / CCC
Warranty	5 Years

Technical Documents

Datasheet

Detailed technical parameters and product overview for reference.

Download

IES File

Photometric data for lighting simulation and design software.

Download

Installation Guide

Step-by-step instructions for safe and correct fixture mounting.

Download
