HB51

The HB51 Series Glass High Bay Light is a high-efficiency luminaire designed for industrial workshops, warehouses, and logistics centers.
Built with durable die-cast aluminum, IP65 protection, and smart dimming capabilities, it provides reliable, high-performance illumination backed by a 5-year warranty.

Key Features

Rugged IP65 Aluminum Design

Constructed with an ADC12 die-cast aluminum housing and tempered glass, providing IP65 waterproof protection and air convection cooling for demanding industrial environments.

High-Efficacy Customizable Lighting

Delivers up to 180 lm/W luminous efficacy across 100W to 240W power options, ensuring maximum energy savings and bright 120° wide beam illumination.

Smart 0-10V Dimming Control

Supports standard 0-10V dimming and DC12V auxiliary power, enabling seamless integration with smart control systems for optimized energy management.

Flexible Mounting Options

Comes standard with a lifting ring, supporting optional lifting hooks, mounting brackets, or pipe adapters for easy installation.

Inquire Now

Technical Specifications

SeriesHB51-Corrosion-Resistant Glass LED High Bay Light
Power100W, 150W, 200W, 240W
Lumen Output15000-43000 lm
Efficacy150 lm/W, 180 lm/W
Input VoltageAC 120-277V 50/60Hz
Color Temperature3000K / 4000k / 5000K / 5700K / 6500K
CRIRa: 80 / Ra: 70
Beam Angle120°
Operating Temperature-30°C to +45°C, RH: 5%-90% non-condensing
IP RatingIP65
IK Rating
IK07
Housing MaterialADC12 + Tempered Glass
MountingStandard with hanging loop, optional hook, bracket mount, 3/4" tube tooth adapter
Dimming0-10V
CertificationsCE / RoHS / CCC / CQC
Warranty5 Years

Technical Documents

Datasheet

Detailed technical parameters and product overview for reference.

IES File

Photometric data for lighting simulation and design software.

Installation Guide

Step-by-step instructions for safe and correct fixture mounting.
