HB103

The HB103 Series Low-Temperature High Bay Light is purpose-built to deliver dependable performance in cold storage facilitity, commercial freezer, and icy industrial space.
Designed to function flawlessly down to -40°C, it provides exceptional energy efficiency and bright, consistent illumination under challenging sub-zero conditions.

Key Features

Low-Temp Solid Capacitor Circuitry

Driven by a specialized power unit with ultra-low temperature solid capacitors, ensuring effortless cold starting and continuous operational stability at -40°C temperatures.

Nano-Vacuum Coated Driver Board

The power supply PCB is treated with an advanced nano-vacuum barrier coating, shielding delicate electronics from condensation and moisture degradation in damp environments.

Encapsulated Dispensing LED Board

The protective glue-dispensing layer seals the light engine, blocking water vapor penetration to safeguard individual LEDs and underlying circuitry from moisture damage.

High-Efficacy Glass Luminaire with Extended Warranty

Constructed with an ADC12 die-cast alloy body and durable tempered glass cover, achieving up to 200 lm/W light output with an IP65/IK08 rating and a 5-year warranty.

Inquire Now

Technical Specifications

SeriesHB103-Cold Storage & Freezer LED High Bay
Power100W, 150W, 200W, 240W
Lumen Output14500-19500 lm, 22500-30000 lm, 30000-40000 lm, 36000-48000 lm
Efficacy150 lm/W, 200 lm/W
Input VoltageAC 120-277V 50/60Hz
Color Temperature3000K / 4000K / 5000K / 5700K / 6500K
CRI150-170lm/W, Ra: 80±2; 200lm/W, Ra: 70±2
Beam Angle120°
Operating Temperature-40°C to +45°C, RH: 5%-95% non-condensing
IP RatingIP65
IK Rating
IK08
Housing MaterialADC12 Alloy + Tempered Glass
MountingStandard with lifting ring; hook, bracket mount and 3/4'' thread adapter optional
Dimming0-10V
CertificationsCE / RoHS / CCC / CQC
Warranty5 Years

Technical Documents

Datasheet

Detailed technical parameters and product overview for reference.

IES File

Photometric data for lighting simulation and design software.

Installation Guide

Step-by-step instructions for safe and correct fixture mounting.
